Stuck on Boot Logo? A Step-by-Step Recovery Guide


  • Crucial: You must download the correct firmware for your specific head unit model. If you're unsure, contact the manufacturer's support before proceeding.

    Preparation is Key: You will need a computer, a USB drive (or SD card), and a small pin or paperclip.

    Step-by-Step Recovery Instructions:

    1.Please unplug all the wires and then reconnect the head unit.

    2.Please download the update.zip via your computer/laptop.

    3.Please make sure to format the USB drive(FAT32 Format)/SD card before copying the update file to it.

    4.Please ONLY put update.zip file in the root directory of the USB drive/SD card, and then insert the USB drive into the USB cable.

    5.Find a pin, press and hold the RST button for 15 seconds to see if you can enter the factory setup page, if you can, select Wipe data/factory reset.

    6.After then, insert the USB drive to the USB cable and re-enter the recovery mode > click "Apply update from SD card or USB" > click "from USB storage" > System update.

    *Last but not the least, please wipe all the datas before proceeding the update.
